Non-woven filter media by Filtecci: All grades and dimensions
Non-woven filter media: Product range
The diversity of non-woven filter medium qualities is enormous and Filtecci delivers them all! Give us your quality requirements or send us a sample (DIN A 4). Then we will find the right non-woven material for you. We are happy to provide you with an on-site consultation. Simply set up an appointment with us.
Types of non-woven filter media
| Non-woven filter medium: | |||
|---|---|---|---|
| Type | Grammage | ||
| Viscous non-woven material FV | 20 – 60 g/m² | ||
| Polypropylene non-woven material FPP | 20 – 70 g/m² | ||
| Needle non-woven material (polyester) FNF | 40 – 150 g/m² | ||
| Spun-bonded non-woven material (polyester) FP | 20 – 100 g/m² | ||
| Waterjet non-woven material (polyester) FPjet | 70 – 150 g/m² | ||
| Multipart non-woven material (polyester) FFUS | 40 – 100 g/m² | ||
Interested: We're here to advise you!
How do I find the right type of non-woven filter media?
The options for filter fleece are vast: Your requirements and a comprehensive product range with fleece components like material, manufacturing type, and weight per unit area must align. The selection process is always caught in a conflict between:
Fine Filtration vs. Economic Consumption
The finer the filtration, the slower the flow of process liquid. The liquid level in the filter quickly rises, triggering the feed.
Fine Filtration – high fleece consumption.
Conversely: a coarse fleece might offer poor filtration but provides good flow with minimal fleece consumption.
Coarse Filtration – lower fleece consumption.
It’s a balance between desired filtration precision and fleece material usage.
Feel free to contact us: We assist in selecting the right filter medium for your needs.
Here is a brief overview of the filter media qualities provided by Filtecci:
- Viscose (FV): Natural fiber, absorbs water, causing the fabric to swell and become tighter, enhancing filtration, but it has poor mechanical properties and tears easily.
- Polypropylene (FPP): Inexpensive medium, commonly used, suitable for coarse machining (turning, milling) on flatbed filters.
- Needle non-woven material (FNF): Thick medium, polyester fiber, excellent filtration even for oil and fine machining like grinding; suitable for casting in combination with a vacuum filter.
- Polyester spunbond medium (FP): Coarse medium, high permeability, resulting in less fine filtration. However, this medium is mechanically robust with high tear resistance.
- Polyester hydroentangled medium (FPjet): Polyester medium for fine filtration, suitable for oil and fine machining like grinding; suitable for casting when used with a vacuum filter.
- Polyester multilayer medium (FFus): Polyester multilayer medium for fine filtration, similar to hydroentangled fleece in application but more cost-effective.
The medium designation looks like this, for instance, FPP 40 500×100: Material (FPP), weight (g/m²), width (mm), length (m). When considering length, consider the outer diameter: will the roll fit your filter system?
